Features:
●Non - contact, low failure rate
●Construction will not affect production
●Installation does not destroy the silo structure, high safety
Technical parameters
|
Parameters |
Specification |
|
Non-linearity （load cell） |
≤0.1%FS |
|
Hysteresis error(load cell ) |
≤0.05%FS |
|
Creep（load cell） |
≤0.03%FS |
|
repeatability（load cell） |
≤0.02%FS |
|
Input resistance |
351±3Ω |
|
Output resistance |
351±3Ω |
|
Insulation resistance |
≥5000mΩ |
|
Sensitivity effective on sensitivity |
0.05%FS/10℃ |
|
Temperature effective on zero |
0.05%FS/10℃ |
|
Reference excitation voltage |
5-12V |
|
Maximum excitation voltage |
15V |
